KLV Series ( Current Configuration)

Customer interface:
Touch screen: Surface acoustic wave or five-wire resistive and four-wire resistive 15.1/17.1/19.1/20.1/21.3 inch touch screen

Touch Resolution: 4096×4096 infrared, resolution 977×737
Monitor: 15.1 / 17.1 / 19. 1/ 20.1 / 21.3 inch LCD TFT monitor ; maximum resolution 1280X1024.

Control system:
Special PC: CPU Core2.0G; Hard disk 160G.
memory: DDR1G Others: video card/net card/multi-media (could be made at the request of customers);

open the side door to expose optical drive, floppy disk drive, ATX switch and audio switch.

Multi-media system:
Amplifier system; stereo Loudspeaker; magnetic-proof

Port:
There are standard PC slots, and all the ports could be offered.

Power supply:
Input: AC220V+-100‰、50Hz+-50‰

Card processor (for selection):
Card reader: ISO standard card/IC card

Printer (for selection):
Automatic paper cut micro printer

Color and dimension:
Cabinet: Steel;
Metallic paint
Color: See picture (could be painted at the request of customers)

Height: 1360mm Width: 500mm Depth: 600mm
Net Weight: 65KG

Software (for selection):
Operating system: Windows2000, WindowsXP
Application software: Chosen by the customers.
